A lattice tower foundation with cable duct integrates structural support for transmission towers with embedded pathways for power and control cables.

Foundation Types

• •Pad & Chimney: Common for lattice towers
• •Pile Foundation: For poor soil conditions
• •Raft Foundation: For uniform load distribution

Cable Duct Integration

• •PVC or RCC ducts embedded in foundation
• •Ducts run to control rooms or cable trenches
• •Bends and junction boxes for cable pulling

Design Considerations

• •Load-bearing for vertical, lateral, and uplift forces
• •Thermal and electromagnetic separation
• •Drainage provisions
• •Manholes for cable inspection
