Cable trays exiting switchgear rooms distribute power from main switchboards to various plant loads via organized routing.

Configuration

• •Multiple tiers for voltage separation
• •Power and control cable segregation
• •Hot-dip galvanized construction
• •Fire barriers at room penetration

Installation

• •Supports at regular intervals
• •Cable ties and markers
• •Grounding continuity maintained
